Model |
33 RYY 10K/10 KS |
33 RYY 20K/20 KS |
33 RYY 30K/30 KS |
33 RYY 40K/40 KS |
33 RYY 50 KS |
33 RYY 60 KS |
Phase |
3-phase in / 3-phase out |
Capacity |
10KVA/ 10KW |
20KVA/20KW |
30KVA/30KW |
40KVA/40KW |
50KVA/50KW |
60KVA/60KW |
Parallel Capacity |
6pcs |
6pcs for standard model; 4pcs for long backup model |
Input |
Voltage |
3 x 380/400/415 VAC (3Ph+N) |
Voltage range |
-30% ~ +20% |
Frequency |
40~70Hz |
Power Factor |
¨R 0.99 @ 100% Load |
Harmonic Distortion (THDi) |
< 3% at full linear load |
Output |
Voltage |
3 x 360/380/400/415 VAC (3Ph+N) |
AC Voltage Regulation (Batt. Mode) |
¡À 1% |
Factor |
1 |
Frequency Range |
Synchronized Range 46~54Hz or 56~64Hz |
Batt. Mode 50/60 Hz ¡À 1% |
Current crest ratio |
3:1(max) |
Harmonic Distortion |
¨Q1 % THD (Linear Load) ; ¨Q3 % THD (Non-linear Load) |
Transfer Time |
Zero |
Waveform (Batt. Mode) |
Pure Sine wave |
Overload capacity |
100-110% for 60 min, 111-125% for 10 min, 126%~ 150% for 1 min; >150% for 400ms |
Bypass |
Nominal Voltage |
3 x 360/380/400/415 VAC (3Ph+N) |
Voltage Range |
-30% ~ +20% (Adjustable) |
Frequency Range (Synchronized |
46~54Hz or 56~64Hz |
Overload Capability |
> 130% 1 minute (default)
Continously working until breaker protection (optional) |
Battery |
Standard
Model |
Capacity |
12 V/9 Ah |
12 V/9 Ah |
12 V/9 Ah |
12 V/9 Ah |
N/A |
Numbers |
(10+10) pcs |
(16+16) pcs |
(16+16) pcs * 2 |
Typical Recharge |
9 hours recover to 90% capacity |
Charging Current |
1-12A Adjustable |
1-16A Adjustable |
Charging Voltage |
+/-136.5 VDC ¡À 1% |
+/-218 VDC ¡À 1% |
Long
backup
Model |
Capacity |
Depending on the applications |
Numbers |
+/- 10 pcs |
+/-16 pcs ~ +/- 20 pcs
(Adjustable) |
32~40 pcs (Adjustable) |
Charging Current |
1-12A Adjustable |
1-18A Adjustable |
Charging Voltage |
+/-136.5 VDC ¡À 10% |
+/-13.65V x N (N= 16~20) |
Efficiency |
AC /Battery Mode: 96%; ECO Mode: 99% |
LCD Panel Indicators |
UPS status , Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions |
Management |
RS -232 / USB |
Supports Windows 2000/2003/XP/Vista/2008, Windows27/8/ 10, Linux and MAC |
SNMP card |
Optional |
Work temperature |
0¡æ~40¡æ |
Altitude |
0 ~ 1500m at full load |
Audible noise |
=60dB |
Storage temperature |
-15¡æ~45¡æ |
Work humidity |
20%~95% |
Noise ( dB ) |
= 60dB |
Product Size (L*W*H) mm |
Standard Model |
630*250*826 |
815*300* 1000 |
N/A |
Long backup Model |
630*250*826 |
815*300* 1000 |
Net Weight (kg) |
Standard Model |
124 |
139 |
225 |
250 |
N/A |
Long backup Model |
28 |
43 |
55 |
58 |
74 |
74 |
