6, PM60K RM

MODEL

RM120/60X-RYY

RM180/60X-RYY

RM240/60X-RYY

RM300/60X-RYY

RM480/60X-RYY

RM600/60X-RYY

PHASE

3-phase in/ 3-phase out

CABINET CAPACITY*

120KW

180KW

240KW

300KW

480KW

600KW

BATTERY TYPE

External Battery

One Power Module Capacity

60KVA/60KW

Max. Power Module No.

2

3

4

5

8

10

INPUT

Nominal Voltage

3 x 380VAC/400VAC/415VAC (3Ph+N)

Voltage Range

305~478 VAC at 70%-100% load; 208~478VAC for <70% load

Nominal Frequency

50/60Hz (Auto sensing)

Frequency Range

40Hz~70Hz

Power Factor

>0.99 at 100% load, >0.98 at 50% load

Harmonic Distortion (THDi)

<3% @ 100% load

OUTPUT

Nominal Voltage

3 x 380VAC/400VAC/415VAC (3Ph+N)

Voltage Regulation

(Steady state)

≦±1% Typical (balanced load); ≦±2% Typical (unbalanced load)

Nominal Frequency

50/60Hz

Frequency Range (Synchronized range)

46Hz~54Hz or 56Hz~64Hz

Overload Capability

1 hour for 110%, 10 mins for 125%, 1 min for 150% and 200ms for >150%

Harmonic Distortion

≦ 2% THD (Linear Load); ≦ 4% THD (Non-linear Load)

Efficiency

Up to 96%

BATTERY / CHARGER

Nominal Voltage

+/-192V~+/-240V (Selectable)

Maximum Voltage

+/-240V (12V x 40 Pcs)

Minimum Voltage

+/-192V (12V x 32 Pcs)

Floating Charge Voltage

2.28V/Cell (2.25~2.33 Selectable)

Boost Charging Voltage

2.35V/Cell

Temperature Compensation

Yes

Maximum Charging Current

(Per Power Module)

18A

PHYSICAL

Cabinet Dimension (DxWxH) mm

1100*600*1475

1100*600*2010

1065*1000*2000

Net Weight (kgs)

308

352

516

516

932

1020

ENVIRONMENT

Operation Temperature

0~40℃

Relative Humidity

0~95% non-condensing

Altitude*

<1000m for Nominal power

IP Class

IP 20

MANAGEMENT

RS-232/ USB

Supports Windows 2000/2003/XP/Vista/2008/7, Linux and MAC

Optional SNMP

Power management from SNMP manager and web browser

STANDARDS

Safety

IEC/EN 60950-1; IEC/EN 62040-1

EMC

IEC/EN 62040-2 Category C3
