2, 33RYY10-60K(S)
|
|
|
|
Picture |
◆ LCD display High Frequency Double Conversion Sine Wave Online UPS 10-60KVA
◆ DSP digital control technology, Zero transfer time
◆ Parallel up to 6 units for 10-40K standard type, 10/20K long backup type, 4 units for 30/40/50/60K long backup type
◆ Three phase sine wave, output Power Factor 1
◆ Wide input voltage range -30% ~ +20%
◆ Wide input Frequency 40-70Hz
◆ support Generator, output HZ be fixed or follow mains
◆ Three adjustable charging current 1-12A/1-16A/1-18A for different models
◆ Adjustable battery numbers
◆ Advanced Input PFC technology, 0.99
◆ Full protection, overload, over voltage, short circuit, over temperature etc.
◆ EPO, RS232/USB communication with monitoring software, optional
◆ Parallel function, SNMP optional 33RYY10K/10KS, 33RYY30K(S), 33RYY40K(S)
◆ 5" and 7'' color touch type LCD display 33RYY20K/20KS, 33RYY50KS, 33RYY60KS
| TECHNICAL SPECIFICATIONS
Model | 33RYY 10K/10KS | 33RYY 20K/20KS | 33RYY 30K/30KS | 33RYY 40K/40KS | 33RYY 50KS | 33RYY 60KS | ||
Phase | 3-phase in/ 3-phase out | |||||||
Capacity | 10KVA/10KW | 20KVA/20KW | 30KVA/30KW | 40KVA/40KW | 50KVA/50KW | 60KVA/60KW | ||
Parallel Capacity | 6pcs | 6pcs for standard model; 4pcs for long backup model | ||||||
Input | Voltage | 3 x 360/380/400/415 VAC (3Ph+N) | ||||||
Voltage Range | -30% ~ +20% | |||||||
Frequency | 40~70Hz | |||||||
Power Factor | ≧ 0.99 @100% Load | |||||||
Harmonic Distortion (THDi) | <3% at full linear load | |||||||
Output | Voltage | 3 x 380/400/415VAC (3Ph+N) | ||||||
AC Voltage Regulation (Batt. Mode) | ±1% | |||||||
Factor | 1 | |||||||
Frequency Range | Synchronized Range 46~54Hz or 56~64Hz | |||||||
Batt. Mode 50/60Hz±1% | ||||||||
Current Crest Ratio | 3:1(max) | |||||||
Harmonic Distortion | ≦1% THD (Linear Load); ≦3% THD (Non-linear Load) | |||||||
Transfer Time | Zero | |||||||
Waveform (Batt. Mode) | Pure Sine wave | |||||||
Overload Capacity | 100-110% for 60 min, 111-125% for 10 min, 126%~150% for 1 min; >150% for 400ms | |||||||
Bypass | Nominal Voltage | 3 x 360/380/400/415 VAC (3Ph+N) | ||||||
Voltage Range | -30%~+20% (Adjustable) | |||||||
Frequency Range (Synchronized Range) | 46~54Hz or 56~64Hz | |||||||
Overload Capability | >130%, 1 minute (default) Continously working until breaker protection (optional) | |||||||
Battery | Standard Model | Capacity | 12V/9 Ah | 12V/9 Ah | 12V/9 Ah | 12V/9 Ah | N/A | |
Numbers | (10+10) pcs | (16+16) pcs | (16+16) pcs*2 | |||||
Typical Recharge Time | 9 hours recover to 90% capacity | |||||||
Charging Current (max.) | 1-12A Adjustable | 1-16A Adjustable | ||||||
Charging Voltage | +/-136.5VDC ±1% | +/-218 VDC ±1% | ||||||
Long Backup Model | Capacity | Depending on the applications | ||||||
Numbers | +/- 10 pcs | +/-16 pcs ~ +/- 20 pcs (Adjustable) | 32~40 pcs (Adjustable) | |||||
Charging Current (max.) | 1-12A Adjustable | 1-18A Adjustable | ||||||
Charging Voltage | +/-136.5 VDC ±10% | +/-13.65V*N (N=16~20) | ||||||
Efficiency | AC/ Battery Mode: 96%; ECO Mode: 99% | |||||||
LCD Panel Indicators | UPS status, Load level, Battery level, Input/ Output voltage, Discharge timer, and Fault conditions | |||||||
Management | RS-232/ USB | Supports Windows 2000/2003/XP/Vista/2008, Windows27/8/10, Linux and MAC | ||||||
SNMP Card | Optional | |||||||
Work Temperature | 0℃~40℃ | |||||||
Altitude | 0~1500m at full load | |||||||
Audible Noise | ≤60dB | |||||||
Storage Temperature | -15℃~45℃ | |||||||
Work Humidity | 20%~95% | |||||||
Noise (dB) | ≤60dB | |||||||
Product Size (L*W*H)mm | Standard Model | 630*250*826 | 815*300*1000 | N/A | ||||
Long Backup Model | 630*250*826 | 815*300*1000 | ||||||
Net Weight (kg) | Standard Model | 124 | 139 | 225 | 250 | N/A | ||
Long Backup Model | 28 | 43 | 55 | 58 | 74 | 74 | ||
|
|
